Sealing device 250 MV, validatable with USB connection
Whether in the doctor's office, in the laboratory or on the hospital ward - with the polystar® 250 MV everything that needs to be sterilized can be safely packaged.
Sealing device 250 MV, validatable with USB connection is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
validatable sealing device
Validatable sealing processes according to DIN EN ISO 11607-2
Description
Description
polystar® 250 MV - Validatable sealing processes according to DIN EN ISO 11607-2
Whether in the doctor's office, in the laboratory or on the hospital ward - with the polystar® 250 MV can be used to safely package anything that needs to be sterilized.
Secure documentation via USB
The individual sealing processes are documented simply and securely. All relevant sealing parameters are saved on the connected USB stick and can later be read out on a standard PC. This means that the sealing processes can be validated according to DIN EN ISO 11607-2 and conform to DIN 58953-7.
Easy operation
The sealing device polystar® 250 MV works according to the heat impulse method, which means it is ready for use immediately. The parameters for temperature, sealing and cooling time are entered via the membrane keyboard. Then the packaging is simply placed between the sealing units and the operating lever is operated. The protective packaging is ready. Controlled in the workflow and consistent in the seam quality.
Suitable for continuous use
The polystar® 250 MV is designed to withstand the demands of a demanding work environment. With its robust construction and reliable performance, you can count on it to maintain peak performance even with continuous use.
maintenance and calibration service
Regular maintenance automatically extends the performance and durability of the polystar® sealing device 250 MV. In addition, the sealing device should be professionally calibrated in accordance with the validation standard. We offer a maintenance and calibration service for this.
Your advantages:
- Validatable according to DIN EN ISO 11607-2; compliant with DIN 58953-7
- Input of the seal parameters via membrane keyboard
- Accurate temperature control with temperature input. Deviation ±5°C
- Sealing and cooling time adjustable in tenths of a second
- The welding time only begins when the target temperature is reached
- Automatic contact pressure
- Integrated piece counter
- error messages with stop function
- USB stick for storing and reading the seal parameters
- Integrated cutting device (hand-operated)
The small work aids such as the plug-in table or film dispenser for a roll of sterilization film in tube form are also practical. This means you have everything quickly to hand in a clear and space-saving manner and can continuously seal your medical packaging.
Technical data
Technical data
Technical data | polystar® 250 MV | |||
---|---|---|---|---|
Seal seam length, max. | 250 mm | |||
seal seam width | 8 mm corrugated embossing | |||
power consumption | 4.0 A | |||
electricity consumption | 0.1 kWh | |||
Dimensions | 440 x 305 x 110 mm | |||
net weight | 8.5 kg | |||
power connection | 230 V/50 Hz | |||
All devices are supplied with a 3m connection cable. Dimensions and weights are approximate. Technical changes reserved! |
product safety
product safety
Manufacturer:
Rische + Herfurth GmbH
Kedenburgstr. 53-59
22041 Hamburg
Tel.: 040 / 656 90 3-0
Email: info@polystar-hamburg.de
WEEE Reg.No. DE48588228 (ElektroG)
CE marking
Optional to the device
FAQ about polystar® 250 MV
Which materials can be sealed with the polystar® 250 MV?
Which materials can be sealed with the polystar® 250 MV?
For example, sterile foils made of paper composite and aluminum oxide polyester foil can be sealed. Other types of material are also possible. Please feel free to contact us.
Can the welding process be validated?
Can the welding process be validated?
Yes, the welding process can be validated according to DIN EN ISO 11607-2 by precisely setting the temperature, welding time, cooling time, as well as reading the parameters and error messages. The contact pressure is set when the machine is calibrated.
polystar® 250 MV

sterilization films
Discover the right sterile film for the polystar® 250 MV. Whether on a roll with or without a side fold or as bags. Whether narrow or wide. Here you will find exactly what you need.
